Rating:0.1A 24VAC 2A 125VAC
Contact Resistance:50mΩ Max.(initial)
Insulation Resistance:100mΩMin
Operating Force:r 400±50gf
Total Travel:2.5±0.5mm
Operatong Life:50,000 Cycles Min
Solder specifications:260ofor5 seconds
Function:OFF-ON
Operating Temerature:-20℃~+70℃
Level kf Drotection:IP67
